The disc granulator can produce spherical pure organic fertilizer, organic-inorganic fertilizer, and bio-organic fertilizer; the particles are uniform, smooth, round, with high strength and good fluidity. The following EMCC will show you how to use the disc granulator and its parameters:
1. How to use the disc granulator
1). Start up: Before starting up, check whether the reducer is filled with gear oil and whether the rotation direction of the disc is correct.
2). Operation: After pressing the start button, the host starts, and observe whether the equipment is operating normally, whether there is vibration, and whether the rotation is stable.
3). Filling: After the equipment is running normally, it can add material and water.
4). Granulation adjustment: After filling, the angle of the disc can be adjusted according to the requirements to make the granules reach the required size.
2. Parameters of disc granulator
| Modelo | Diametro de plato (mm) | Profundida de plato(mm) | Velocidad de trabajo (r/min) | Capacidad(t/h) | Potencia(kw) | Dimension(mm) | |
| ZL-500 | 500 | 200 | 32 | 0.02-0.05 | 0.55 | 650x600x800 | |
| ZL-600 | 600 | 280 | 33.5 | 0.05-0.1 | 0.75 | 800x700x950 | |
| ZL-800 | 800 | 200 | 21 | 0.1-0.2 | 1.5 | 900x1000x1100 | |
| ZL-1000 | 1000 | 250 | 21 | 0.2-0.3 | 1.5 | 1200x950x1300 | |
| ZL-1200 | 1200 | 250 | 21 | 0.3-0.5 | 1.5 | 1200x1470x1700 | |
| ZL-1500 | 1500 | 300 | 21 | 0.5-0.8 | 3 | 1760x1500x1950 | |
| ZL-1800 | 1800 | 300 | 21 | 0.8-1.2 | 3 | 2060x1650x2250 | |
| ZL-2000 | 2000 | 350 | 21 | 1.2-1.5 | 4 | 2260x1650x2250 | |
| ZL-2500 | 2500 | 450 | 14 | 1.5-2.0 | 7.5 | 2900x2000x2750 | |
| ZL-2800 | 2800 | 450 | 14 | 2-3 | 11 | 3200x2200x3000 | |
| ZL-3000 | 3000 | 450 | 14 | 2-4 | 11 | 3400x2400x3100 | |
| ZL-3600 | 3600 | 450 | 13 | 4-6 | 18.5 | 4100x2900x3800 | |
