MQX Superfine Ball Mill Production Line

DEVICE DETAILS:

MQX ultrafine ball mill powder production line is suitable for ultrafine powder final product with fineness of about 1250 mesh. This ultra-fine powder production line does not only meet customers’ requirements for fineness, but also meets the big yield requirements of customers. It is an enclosed production line. In the mineral processing industry, we seek efficiency, reliability, stability and persistence to help customers achieve the long-term and stable income.

TECHNICAL PARAMETERS:

Capacity(t/h)	Jaw Crusher	Hammer Crusher	Elevator Bucket	Belt Feeder	ScrewConveyor	BallMill	ElevatorBucket	Classifier	PowderCollector	Dust Catcher
0.3-0.6	PE-150*250	PC400*300	T210*7M	PCB400*2.5M	LS200*6M	MQX1.2*4.5M	T210*7M	FJ450	XC600	DMC112
1-1.5	PE-150*250	PC400*300	T210*9M	PCB400*2.5M	LS200*6M	MQX1.5*5.7M	T210*9M	FJ450	XC700	DMC120
2-3	PE-250*400	PC400*600	T210*11M	PCB400*2.5M	LS200*7M	MQX1.8*7.0M	T210*11M	FJ500	XC900	DMC160
3-3.5	PE-250*400	PC400*600	T315*13M	PCB500*4M	LS315*10M	MQX2.2*7.0M	T215*11M	FJ800	XC1100	DMC224
4-6	PE-400*600	PC600*800	T315*15M	PCB500*4M	T315*15M	MQX2.4*9.0M	T315*15M	FJ1000	XC1300	DMC240
6-8	PE-400*600	PC600*800	T400*19M	PCB650*4M	T400*19M	MQX3.0*13.0M	T400*19M	FJ1000	XC1300	DMC300

ADVANTAGE:

1.Reasonable inlet and outlet designimproves equipment production stability;

2.High manganese steel linerismore wear-resistant and with longer working life;

3.Theclosed cycle of productioncan ensure both fineness and production efficiency;

4.The equipment can independently complete the whole production process from raw material crushing equipment, transport, milling to the finished product collection, storage and packaging.

5.It canalso use special ball mill lining for special industryto get non-ferrous products.

WORK PRINCIPLE:

After primary crushing by a small jaw crusher crushed materials enter into hammer crusher for a second crushing and then is lifted into big hopper by bucket elevator through a frequency conversion screw feeder into the MQX superfine mill for fine grinding. The powder grinded will be transported by bucket elevator to the vortex grader for grading screening. Unqualified powder will return to ball mill and qualified powder will be brought into the powder collector by updraft cyclone. Most of the qualified powder will be separated from air flow in the collectorand be collected. Trace amount of fine powder follows airflow into the pulse dust catcher. With this required fineness powder is gathered up and meanwhile air is purified by the dust catcher.
